Bohler Uranos 2000 SMC Multi Process Welder

Features

• Lightest 200A multi process in our range - 12.8KG
• 5KG reel capacity
• 2 roll wire feeder
• Synergic lines up to 5MM thickness material
• Pulse DC Lift TIG (up to 2500Hz)
• Programmable welding setup memory (8 jobs)
• ArcDrive technology - modified waveform for massively reduced spatter and improved arc characteristics
• Digital display
• Multi process - MIG, DC Lift TIG & MMA
• Weldable materials - Mild steel, stainless steel, aluminium & FCAW
• 5.7Kva generator requirement - One of the lowest on the market
• Synergic MMA
• Best in class for aluminium MIG welding
• Made in Italy
• 3 year warranty

Feature Focus #1 - Lightweight & portable

The entire machine weighs less than a typical reel of MIG welding wire. At 12.8KG it is the lightest fully synergic multi process welder on the market. It beats out it's closest competition from industry leading brands, including:

• The Fronius TransSteel 2200C - 15.5KG
• The EWM PicoMIG 185 - 16KG
• The Miller MPI 220P - 16KG
• The GYS Multi Pearl 210-2 - 16KG
• The Lincoln Speedtec 200C - 17.2KG

The fact that the Bohler Uranos 2000 SMC is so lightweight means that it is easier to transport from place to place, simply throw it in the back of the van and move onto the next job.

Feature Focus #2 - ArcDrive technology

ArcDrive was developed by Bohler Selco over many years of research, development & testing. The results of this effort is a highly stable, reactive welding arc that offers superb controlability and outstanding spatter free welds.

ArcDrive is a modified waveform. This means that the way the welding arc works is different to other welding machines you may have used. You'll instantly feel the difference in arc characteristics and notice the benefits when you get on "on torch time" with the Bohler Uranos 2000 SMC.

This feature means the machine is perfect for a vast range of welding applications, including:

• Solid wire welding
• Flux cored wire welding
• Hardfacing
• Brazing

Feature Focus #3 - Synergic control panel

One major bugbear for many welders is how tricky it can be to dial in your weld parameters perfectly. Whilst we're firm believers that parameter setting is a key skill to develop as a welder, the Bohler Uranos 2000 SMC can help those who want to eliminate the guesswork whilst trying to achieve that perfect weld.

The fully synergic control panel allows the user to programme the machine with the diameter of welding wire being used, the type of material being welded, the type of shielding gas being used and the thickness of the material being welded. The machine will then "spit out" the perfect settings for the job at hand.

In addition to this, the user can programme the weld position and also trim / adjust the weld settings to suit their preferences.

Once the user has dialled in their settings they can then then store them to one of 8 memory slots. That's perfect for ensuring you get consistent welds for any repeat jobs you get in.

Feature Focus #4 - Pulse DC lift TIG welding

Most multi process welding machines will have a DC lift TIG feature included as standard. So what makes the Bohler Uranos 2000 SMC any different?

It has a pulse feature! What do that mean?

• Decreased heat input into the parent material
• Improved weld profile and looks
• Increased travel speed
• Narrower welding bead
• Produces a smooth ripple effect in the weld bead

This feature is not present in any other synergic 200A multi process machine on the UK market. Yet another stand out feature on the Bohler Uranos 2000 SMC.

Technical Specifications

• Duty cycle (40C ambient temperature) - 35% @ 200A / 60% @ 160A / 100% @ 130A - Best in class
• Duty cycle (25C ambient temperature) - 100% @ 220A
• Maximum output - 200A 240V
• Weight - 12.8KG
• Generator requirement - 5.7KVA
• Input voltage - 230V
• OCV - 58VDC
• Protection class - IP23S
• Power supply cable 3 x 2.5MM2 - 2MTR
• Current range - 3A - 220A
• Wire diameter range (steel) - 0.8MM - 1MM
• Wire diameter range (aluminium) - 0.8MM - 1MM
• Wire diameter range (flux cored wire) - 0.9MM - 1.2MM
• Wire speed range - 0.5M - 16M per minute
• Wire feed rollers - 2
• Maximum wire reel capacity - 5KG
