Miller Migmatic 320i MIG Welder - 3 Phase

Credit subject to status and minimum order value.
Fast check - won't affect your credit rating.
Delivery
All orders shipped with UPS Express.
Always free shipping for orders over US $250.
All orders are shipped with a UPS tracking number.
Returns
Items returned within 14 days of their original shipment date in same as new condition will be eligible for a full refund or store credit.
Refunds will be charged back to the original form of payment used for purchase.
Customer is responsible for shipping charges when making returns and shipping/handling fees of original purchase is non-refundable.
All sale items are final purchases.
Help
Give us a shout if you have any other questions and/or concerns.
Email: [email protected]
Phone: +1 (23) 456 789
Categories:
Free Delivery
For orders over £75
Interest Free Finance
Up to 10 months
Payment Secured
Safe shopping with us
Key Features
- 15MM maximum weld thickness on mild steel
- 30A - 300A output
- Made in Italy
- 400V input supply
- Digital display
- Duty cycle - 35% @ 320A
- Fully synergic MIG control
- 3 year warranty
Features
- Digital meter - The Migmatic 320i is quipped with a digital display which shows all of your welding parameters
- Fully synergic control - Control your parameters by setting your material type, wire diameter & material thickness
- Adjustable Run- In and Burnback allows the user to optimise arc starts & stops, reducing wire stubbing or wire burning back onto the contact tip.
- Thermal Protection with indicator light. Prevents damage when there is a risk of overheating, due to over duty cycle or reduced airflow.
- 2-4 Step trigger mode with gas preflow and post flow function in 4 step mode.
- Professional 4 roll driven wire drive.
- Synergic control with programs for steel, stainless, aluminium and Mig Brazing.
- Superior welding characteristics - Due to the modern transformer design, excellent starting and a very stable welding arc.
Technical Specifications
- Input Power - 400V 3 Phase
- Rated Output - 320A @ 35% Duty cycle
- Voltage Range - 13V - 35V
- Wire Speed - 1.5M / Min - 20M/ Min
- Wire Diameter - 0.6MM - 1.2MM
- IP Rating - IP23S
- Max open circuit voltage - 70 VDC
- Dimensions - H: 830MM W: 470MM D: 1070MM
- Weight - 57KG
Includes Genuine Binzel Torch & Regulator
Brand | Miller |
---|---|
GYS Offer | No |
Lead Time | Call To Discuss Lead Time & Availability |
Is Laser Product | No |
Max Weldable Thickness | 3MM, 5MM, 8MM, 10MM, 12MM |
Input Voltage | 400V |
Warranty Period | 3 Year |
Max Wire Reel Capacity | 15KG |
Short Description | Key Features
|
POA | No |
