Jasic 352 Multi Process Compact MIG Welder - 3 Phase
Availability:
In stock
SKU
ZXJM-352C
£2,115.12
£1,762.60
Availability
In Stock
Check your eligibility
Fast check - won't affect your credit rating.
Categories:
hidden
Free Delivery
For orders over £75
hidden
Interest Free Finance
Up to 10 months
hidden
Payment Secured
Safe shopping with us
Key Features
- 15MM maximum weld thickness on mild steel
- 50A - 350A output
- Invert based multi process machine
- Duty cycle - 100% @ 350A
- 4 roll wire feeder
- 5 year warranty
Related Products
Key Features
- Includes MIG Torch, Work Return Lead, Earth Clamp & Regulator
- IGBT MIG MAG/MMA/Lift-Arc TIG Inverter
- Digital amp and voltmeter
- High duty cycle
- Advanced control circuitry
- Burn back control & wire inching
- Suitable for 0.6MM - 1.2MM wire
- 2T/4T trigger function
- Power & status LED’s
- Gas check function
- Variable inductance
Technical Specifications
- Input Voltage - 400V 3 Phase
- Input Current - 22A
- Amperage Range - 50A - 350A
- No-Load Voltage - 65V
- Wire Feed Speed - 1 - 16 M/ Min
- Duty Cycle - MIG 350A @ 100% / MMA 350A @ 80%
- Max Wire Spool Size - 15KG
- Arc Force Range (MMA) - 0-250
- Power Factor - 0.93
- Protection Class - IP21S
- Dimensions - 760MM X 365MM X 585MM
- Weight of Machine & Wire Feeder - 49KG
You can find a link to Jasic UK's information page for this machine here.
The standard JM-352C package includes a 3M Starparts Titanium MB36 MIG torch, G-Tech gas regulator, earth lead with clamp & gas hose with connections. However, if you'd like a more complete package then suitable 'Ready to Weld Packages' for this machine can be found below:
| Brand | Jasic |
|---|---|
| GYS Offer | No |
| Is Laser Product | No |
| Max Weldable Thickness | 3MM, 5MM, 8MM, 10MM, 12MM, 15MM |
| Input Voltage | 400V |
| Warranty Period | 5 Year |
| Max Wire Reel Capacity | 15KG |
| Short Description | Key Features
|
| POA | No |
